The Piranha PAVBDB HEX 3/16" coring bit is part of Piranha's second-generation PAVBDB HEX series, built with vacuum-brazed synthetic diamond technology for a strong, reliable bond between the diamonds and the bit and consistent cutting across a wide range of materials. The hexagonal shaft was added to this generation for direct use in a standard drill chuck, making it ideal for precise small-diameter coring in porcelain, natural stone, and similar hard surfaces. It works for both dry and wet coring; because this is a small-diameter (sub-12mm) bit, a water feed is recommended to maximize bit life and cut quality. A variable-speed tool is recommended so speed can be matched to the density of the material being drilled.

Key features

• Vacuum-brazed synthetic diamond construction for a strong diamond-to-bit bond and reduced residual stress
• Hexagonal shaft designed to fit standard drill chucks for easy small-diameter coring
• 3/16" (5 mm) diameter — the smallest size in the PAVBDB HEX series (which spans 3/16" to 5" / 5 mm to 130 mm)
• Suitable for both dry and wet coring across hard materials including porcelain and natural stone
• Water feed recommended for sizes under 12 mm to extend bit life and improve cut quality
• Variable-speed tool recommended to match drilling speed to material density

Specifications

• Brand: Piranha
• Series: PAVBDB HEX (2nd generation)
• Diameter: 3/16" (5 mm)
• Shaft Type: Hexagonal (drill-compatible)
• Diamond Bond: Vacuum brazed
• Use: Wet / Dry coring
• Recommended Tool: Variable-speed drill/grinder
